VALCAM-EL

New Slider Expansion Type Added to VALCAM^®100, 140, 200

• Machining possible even at positions away from the panel edge.
• High flexibility in mounting tools.
• No need for block design and arrangement.
• Same mounting dimensions as VALCAM of the same size.

Features of VALCAM-EL

Expansion of Cam Slider Mount Face

By extending the cam slider up to 60mm in the machining direction and expanding it by 40mm in height compared to the existing VALCAM, the layout design of tools mounted on the unit becomes more flexible and easier.

Flexible Design with High Degree of Freedom

Wide Mount Face for Large Tools:

Unlike existing cam units, which struggle with large tools that exceed the Mount face, VALCAM-EL features a wide upper Mount face, allowing for the installation of larger tools.

Reinforced Structure for Heavy Equipment:

Tools like cam pads, which were difficult to install due to weight limitations on the Mount face, can be installed with VALCAM-EL thanks to its reinforced structure.

Reduced Workload with No Need for Block Design and Arrangement:

Areas where blocks were previously attached and adjusted to the slider because the tool couldn't reach the machining part no longer require the cumbersome design and arrangement of blocks, thus reducing the workload.

Same Mounting Dimensions as VALCAM100, 140, 200

VALCAM and VALCAM-EL have mounting compatibility.

Note:

The total width of the cam for VALCAM-EL100 and 140 is the Mount face width + 10mm.

Product Specifications

Grade	Mount Face width mm	Working Force [kN (tonf)]		Working Force	Working Angle (5ﾟIncrements) Working Angle	Catalog No.	Spring Type	App.
		1,000,000 strokes	300,000 strokes
	100	116.1 (11.8)	139.2 (14.2)	0°～70°	VACPEL100
	140	159.3 (16.3)	191.1 (19.5)	0°～70°	VACPEL140
	200	197.6 (20.1)	230.5 (23.5)	0°～70°	VACPEL200

Gas Spring Coil Spring Make sure to check your conditions of use.
